High Rigidity:

• FEA Analysis
• High rigidity structure design
• 3 Axis ball screw pre stressing

High Reliability:

• Roller type motion system
• 3 Axis absolute motor

High Efficiency:

• V-32A.V-42A.V-52A with high torque spindle motor
• Rapid feed rate 48/48/36mm
• Spindle speed 12,000rpm(optional)
• Tool change time T to T 1.8sec
• Tool change time C to C 4sec

High Flexibility:

• 30 tools magazine available
• 4/5 axis rotary table available
• Front/Rear Chip Disposal available

High Rigidity:

• FEA Analysis
• High rigidity structure design
• Dual nuts ball screw design in X/Y axis
• Rotary table use DD motor
• Roller type guide way (X/Y/Z axis)
• Embedded rotary table design

High Reliability:

• Roller type motion system
• Ball screw bearing lubrication system design
• Dual chip auger
• Three axis optical scale
• Rotary table compensaion adjustment system
• Dynamic collision monitoring system
• Moveable ATC design

High Efficiency:

• Rapid feed rate 36/36/30 mm
• Spindle speed 15,000 rpm
• 5 axis machining simultaneously
